Type

Modular demountable partition is composed of double independent panels that allows access points throughout the length of the system. The total thickness of this product is 108mm (4 1/4″).

Floor & Ceiling

Aluminum floor and ceiling track with a view of 3mm (1/8″).

Structure

Freestanding structure that is composed of vertical and horizontal elements that are anodized, lacquered aluminum or galvanized steel, depending on the project requirements.

PA 100 OPAQUE

Modules

The panels are placed through a clipping system, allowing for an easy and quick installation. Space between each panel is 3 to 5mm (1/8″ to 13/64″)

Melamine 19mm (3/4″) panels with various finishes available (natural wood veneer or HPL) with a 3mm (1/8″) PVC edge banding. Acoustic insulation through 60mm (2 3/8″) mineral rock wool with a density of 40 kg/m³.

Acoustic Insulation

Certified by a certified third party acoustics Laboratory, with an acoustic insulation of 46 to 53 dB Rw.

PA 100 GLASS

Modules

Double glazed framed modules with glass of 4 or 6mm (3/16″ or 1/4″) . There is an interior space between the two panels of glass which allows for incorporation of blinds up to 80mm (3 1/8″) thick.

Acoustic Insulation

Certified by a certified third party acoustics Laboratory, with an acoustic insulation of 41 dB Rw.
