Line Systems have created a solution to focus on both the aesthetics and acoustics to fit a variety of high-quality specifications for the consumer. The Glass Acoustic is built with two glass panels which allows an attractive design with an acoustic performance up to 46 dB Rw. The partition also allows for a choice of single or double glazing further increasing the customization of each project.
TECHNICAL INFORMATION
downloads and details
Type
Our demountable partition system is composed of 10/12mm (3/8″ / 1/2″) laminated or tempered glass which allows for total or partial glass blindness. Total profile width of 108mm (4 1/4″), this system allows 1-3 glass panels.
Structure
The structure of the Glass Acoustic is a continuous glass system. A union between the glass is created to achieve a high-transparency L-shape PVC profile.
Floor & Ceiling
The Glass Acoustic has main profile with side and central covers on the floor with a view of 36mm (1 7/16″). The main profile with side and central covers and U profile for tolerance adjustment on the ceiling which has a view of 66mm (2 5/8″).
Acoustic Performance
Certified by an accredited third party lab with an acoustic performance of 46 dB Rw.
Brochures
This product is not available in Quebec. Therefore some of the following downloads may not be available in French.
