BlastShield™ Model BL6000

The McKEON BlastShield™ Model BL6000 blast resistant door was tested and certified in accordance with ASTM F2927-21 Standard Test Method for Door Systems Subject to Airblast Loadings.
McKeon BlastShield™ Model BL6000 London

TECHNICAL INFORMATION

downloads and details

Customer-Favourite Commercial Rollup Doors

Depending on your needs, we have an extensive selection of high-performance, energy-efficient and fire-rated products to choose from, including the following.

SECURE ROLLUP GARAGE DOORS

If you want top performance and high-speed operation, our high-performance security doors will have you covered. These doors are among the best overhead door investments with some of the lowest overall lifetime costs:

  • Extreme® 300 Series High-Performance Rollup Door: This springless series door is high-speed and intelligent thanks to the Apex SmartController. Designed to last 300,000 maintenance-free cycles, the Extreme 300 has it all.
  • Extreme® 1024 Long-Lasting Rollup Door: The Extreme 1024 high-performance rapid-roll door offers intelligent Apex SmartController operation and can withstand an impressive 1,000,000 maintenance-free cycles.
  • StormDefender™ Safe Room Door: This commercial rollup door is designed explicitly with security and life safety in mind, guarding you and your building against tornadoes, hurricanes and other severe weather.
  • EntryDefender™ High-Security Door: The EntryDefender™ Door meets the U.S. Department of State Standard for forced entry for a five-, 15- and 60-minute mob-style attack.
FIRE-RATED ROLLUP SERVICE DOORS

Rollup fire doors are rated structural fire barriers that help block the spreading of hazardous fire and smoke by compartmentalizing a building space and keeping the event isolated. Many buildings today mandate the placement of rolling steel fire doors as a standard safety precaution.



The Firemiser Insulated Rolling Fire Door is perfect for an exterior application and reduces sound transfer thanks to mineral wool insulation. Mineral wool insulation also minimizes thermal transfer, which can help you with temperature control inside your building. Opt for the SmokeShield™ seal package for your fire-rated door if you’re required to conform to UL 1784 or want an additional barrier to eliminate smoke migration throughout your building.

The McKEON BlastShield Model BL6000 not only passed all the requirements of the ASTM F2927-21 shock tube test, it achieved extremely high results for the industry.

  • The BlastShield BL6000 achieved an ASTM Damage Level Category II.
  • The unit, with its unique ZX curtain slat configuration, sustained no greater than 1/2 inch permanent deformation and remained operable.
  • The witness chamber results were recorded as “No debris was observed.”
  • The BlastShield BL6000 is unsurpassed by any other overhead coiling door with a tested Peak Reflected Pressure of 10 psi (1,440 psf).


Consider the possibilities. Building requirements are increasingly requiring blast resistant doors. The BlastShield BL6000 blast resistant door can be specified for use in many different applications such as educational facilities, chemical and processing facilities, pharmaceutical plants, manufacturing environments, automotive assembly plants, hazardous storage facilities, data centers, DOD, DOE and DOJ facilities, and research facilities.


Certifications

Independently tested by Intertek to ASTM F2927-21


Operation

Power motor operation


Size

Sizes based on desired Damage Level Category, Peak Reflected Pressure and project design requirements


Finishes

Dusky Charcoal


Powder Coat of any color as selected


Project-specific design specifications and details will be generated for each blast resistant door based on those exclusive project requirements.

Please contact McKEON Engineering for further information.

Product Specifications

Specifications & Tech Data
